RV021Z6M-400-40Active model

2.1 inch Round LCD Display – 480*480 IPS Panel RGB SPI LCD Module

Size: 2.1 inch round lcd display IC Driver: ST7701S Resolution: 480*480 Interface: 3SPI+18RGB Luminance: 300 cd/m² Touch: with touch/ no touch

Size: 2.1 inch
Resolution: 480×480
Brightness: 300 cd/m²
Interface: RGB, SPI
Touch: No

Designed for integration

Product overview.

This small size 2.1 inch tft lcd display panel you could choose two type, with touch or no touch, it is a round lcd display panel with RGB+SPI interface, all view angle.

we custom different size of LCD module, add touch screen, custom for the brightness and control board, we provide one-stop LCD solution include capacitive touch, drive board, FPC and so on.

Key features

Size: 2.1 inch round lcd display
IC Driver: ST7701S
Resolution: 480*480
Interface: 3SPI+18RGB
Luminance: 300 cd/m²
Touch: with touch/ no touch

Technical reference

Specifications.

Values are model-specific. Review document revisions and any verification notes before integration.

Display

Parameter	Value	Unit	Notes
Size(inch)	2.1	—	—
Resolution	480×480	—	—
Size	2.1 inch round lcd display	—	—

Optical

Parameter	Value	Unit	Notes
Brightness (cd/m²)	300	—	—
Luminance	300 cd/m²	—	—

Touch

Parameter	Value	Unit	Notes
Touch	with touch/ no touch	—	—

Environmental

Parameter	Value	Unit	Notes
Wide Temperature	No	—	—

Interface & pins

Parameter	Value	Unit	Notes
Interface	RGB, SPI	—	—
IC Driver	ST7701S	—	—
Interface	3SPI+18RGB	—	—

Drawings & technical resources

Product documents.

Contact our team for the current datasheet or mechanical drawing.
