RV024VGM-420-40Active model
2.4-inch TFT LCD Display – 480*640 IPS TFT LCD display module with control board
RV024VGM-420-40 is a 480*320 resolution RGB interface TFT LCD module, IC Driver is ST7701S, with Operating Temperature -20 to +70 degrees and Storage Temperature degrees, LCM Luminance is 420nit. The interface is acceptable to change to SPI, MCU and so on, and the brightness is acceptable to customized, and supporting HDMI board and other LCD […]
- Size
- 2.4 inch
- Resolution
- 480×640
- Brightness
- 420 cd/m²
- Interface
- SPI
Designed for integration
Product overview.
RV024VGM-420-40 is a 480*320 resolution RGB interface TFT LCD module, IC Driver is ST7701S, with Operating Temperature -20 to +70 degrees and Storage Temperature degrees, LCM Luminance is 420nit. The interface is acceptable to change to SPI, MCU and so on, and the brightness is acceptable to customized, and supporting HDMI board and other LCD control boards, such as control for video, with USB, VGA interface and so on.
Technical reference
Specifications.
Values are model-specific. Review document revisions and any verification notes before integration.
Display
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Size(inch) | 2.4 | — | — |
| Resolution | 480×640 | — | — |
Optical
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Brightness (cd/m²) | 420 | — | — |
Interface & pins
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Interface | SPI | — | — |
No matching parameters.
Drawings & technical resources
Product documents.
Contact our team for the current datasheet or mechanical drawing.
Before you integrate
Product questions.
Have a technical question? Send your project requirements below.
Let’s check the fit
Your application.
Our engineering review.
Share your interface, controller, touch and mechanical requirements for RV024VGM-420-40.
